Laboratory Stand "Universal Complex for Electrical Installation Work"

Technical Parameters:

Voltage: 220 V.

May be equipped with transport casters.

Functional Features:

Assembly table:

Made of steel profile with an integrated work surface and drawers for storing working tools.

Built-in electrical module:

Protected sockets:

Power supply 1 ~ 220 V, 50 Hz, 3 A – 2 pcs.

Power supply 1 ~ 36 V, 50 Hz, 3 A – 2 pcs.

Power supply 1 ~ 12 V, 50 Hz, 3 A – 2 pcs.

Adjustable power supply: 2…+30 V, 3 A – 1 pc.

Measuring instruments:

AC voltmeter: 0–250 V – 1 pc.

AC ammeter: 0–2 A – 1 pc.

Perforated mounting panel:

Dimensions: 500×800 mm.

Material: galvanized steel with elongated perforated holes (5×40 mm, optional) for repeated installation and removal of electrical components during training.

Protective features:

The built-in electrical module may include additional protection devices, power supplies, and measuring instruments upon agreement with the customer.

Exhaust device connection (optional):

Diameter of the connected exhaust device: 100 mm.

This comprehensive training platform consists of an assembly table and additional sets of components placed on the mounting panel, providing students with hands-on experience in the field of electrical engineering.

Structurally, the complex includes:

An assembly table made of steel profile with an integrated work surface and drawers for storing tools.

A built-in power supply module located above the work surface.

A frame made of aluminum profile with a perforated mounting panel for installing and removing electrical components during training.

Training Projects:

Fundamentals of electrical installation: Study of the basic principles of electrical installation and wiring.

Electrical circuit assembly: Practice in assembling and connecting various electrical circuits using the perforated mounting panel.

Electrical circuit commissioning: Training in diagnostics and adjustment of assembled electrical circuits.

Measurement of electrical parameters: Use of the built-in voltmeter and ammeter to measure voltage and current in assembled circuits.

Experiments with adjustable power supply: Conducting experiments with adjustable power supply settings (2…+30 V) for various circuit configurations.

Educational Advantages:

Practical experience: Students gain hands-on skills through direct interaction with real electrical components and assembly of various circuits.

Comprehensive coverage: The stand covers all key aspects of electrical installation, including wiring, commissioning, and measurement.

Modular design: Allows flexible experimentation with different circuit configurations, enhancing understanding of complex systems.

Safety-oriented: Equipped with protected sockets and optional additional safety features to ensure safe operation during experiments.

Robust construction: The perforated mounting panel is made of galvanized steel, ensuring long service life and wear resistance.

Conclusion

The training laboratory stand "Electrical Installation Complex" is a modern educational tool that combines real components with advanced simulation capabilities. Its robust construction, interactive features, and wide range of possibilities make it an essential solution for teaching and learning modern methods of electrical installation and electrical engineering.
