The laboratory stand "Operation and Connection of Electricity Metering Devices" is designed for studying the principles and methods of installation and testing of electricity meters.
Supply voltage: 380 V.
May be equipped with transport casters for mobility.
Made of steel profile with a work surface and a pull-out drawer for convenient storage of tools.
Power supply ~220 V, 50 Hz, 3 A – 2 pcs.
Power supply ~36 V, 50 Hz, 3 A – 2 pcs.
Power supply ~12 V, 50 Hz, 3 A – 2 pcs.
Cables are laid in a cable channel, ensuring neat and organized wiring during training.
Allows gradual load variation when testing a single-phase electricity meter.
Connection and testing of a single-phase electricity meter (included in the set).
Connection and testing of a three-phase electricity meter (included in the set).
Electricity meter
Active energy meter
Three-phase switch
E27 lamp holders – 2 pcs.
Cable tray
Terminal block
This comprehensive training stand consists of an assembly table and additional sets of equipment installed on the working field, providing students with practical experience in electricity metering systems.
An assembly table made of steel profile with an integrated work surface and a pull-out drawer for storing tools.
A built-in power supply module located above the work surface.
An aluminum profile frame with a perforated mounting panel for fixing and testing electrical components.
Study and testing of the functionality of single-phase electricity meters under different loads.
Analysis and testing of three-phase electricity meters under different operating conditions.
Gaining experience in cable routing in a cable channel for safe and neat electrical wiring organization.
Experiments with gradual load variation to observe the behavior of meters during testing.
Students gain practical experience interacting with real components of electricity metering systems and assembling various connection schemes.
The stand covers all key aspects of electricity metering device installation — single-phase and three-phase meters.
Flexible configuration using interchangeable panels enhances understanding of complex systems.
Equipped with protected sockets and adjustable power supplies, ensuring safe operation during training.
The aluminum profile frame and perforated panel ensure long service life and wear resistance.
The laboratory stand "Installation of Electricity Metering Devices" is a modern educational equipment that combines real components with advanced simulation capabilities. Its robust frame, interactive functions, and wide range of possibilities make it an essential solution for teaching and training in modern electrical engineering and energy metering technologies.
